Binding

Bookbinding systems for high volume production to stand alone machines and integrated modules for high efficiency.

Cabs 4000V/6000

This compact perfect binding line comprises three high-performance units: the modular gathering machine MG-600, the fully automatic perfect binders SB09V/SB17, and the three-knife trimmer HT-110. Together, this trio enables you to process both small and large orders efficiently and with top-notch quality, achieving up to 4000/6000 books per hour. Thanks to Horizon’s innovative TOUCH&WORK technology, the CABS 4000V/6000 system are incredibly user-friendly. With a wide range of optional accessories, it can be tailored to meet your specific needs, ensuring that your binding operations are not only efficient but also versatile and adaptable to various production demands.

Production volume

small to large editions

PRINTING TECHNOLOGY

for offset and digital printing

FORMATS

max. 275 x 385 mm
min. 105 x 148 mm (width x back length)

Speed

max. 4000 or 6000 books/h

iCE BINDER BQ-500

The iCE Binder BQ-500 represents the fifth generation of Horizon perfect binders, setting a new standard with its fully automated 4-clamp high-performance system. Not only does it boast a completely new design, but it has also been significantly advanced in all aspects. Its integrated Auto-Calculation System, combined with TOUCH&WORK technology, ensures consistently perfect binding quality without the need for manual adjustments. Versatile and efficient, the iCE Binder BQ-500 is suitable for both EVA hotmelt and PUR adhesive applications, offering flexibility and precision in your binding operations.

Production volume

small to large editions

PRINTING TECHNOLOGY

for offset and digital printing

Speed

max. 1,350 cycles/h with EVA hotmelt
max. 1,000 cycles/h with PUR

BQ-280PUR

PUR adhesives boast numerous benefits, including durability, ease of use, and eco-friendliness. The BQ-280PUR from Horizon is a perfect binder designed to optimally prepare the product’s adhesive area, maximizing the advantages of PUR to create exceptionally durable bindings. This makes the BQ-280PUR an ideal choice for producing medium to small runs of books as well as individual copies, providing both quality and versatility in your binding operations, ensuring your finished products stand the test of time with superior binding strength.

Production volume

small to medium editions

PRINTING TECHNOLOGY

for offset and digital printing

Speed

max. 500 cycles/h

BQ-270V

This compact and user-friendly single-clamp perfect binder is ideal for fully automated EVA productions, perfectly suited for medium to small batch sizes, right down to individual copies. An integrated measuring station enhances efficiency by quickly determining book thickness, a clever feature that boosts output in variable single-book production. Additionally, the input and output stations are positioned closely together, enabling continuous loading and unloading from a single location. Optional accessories, such as a barcode reader, allow for the verification of covers and content, ensuring accuracy and consistency in your production process.

Production volume

small to medium editions

PRINTING TECHNOLOGY

for offset and digital printing

Speed

max. 500 cycles/h

BQ-160 EVA+PUR

When space is at a premium in your operation, this professional compact perfect binder is an excellent choice. Despite its small footprint, it delivers all the hallmark features you expect from Horizon. It’s particularly suited for small runs, making it ideal for copy shops or digital print environments. Easy to operate and requiring minimal material preparation, it ensures lasting, stable binding results, even with challenging papers or thick blocks. The BQ-160 is available in either an EVA hotmelt or a PUR version, offering flexibility to meet your specific binding needs while accommodating the constraints of your workspace.

Production volume

small to medium editions

PRINTING TECHNOLOGY

for offset and digital printing

Speed

max. 180 cycles/h (binding with cover)

Options

ESF-1000

The end sheet feeder, ESF-1000, applies the folded front and end sheets to the book block, accommodating various types of book blocks, such as loose-leaf collections, folded signatures, and blocks that are either glue assisted or thread sewn. Its standard thickness measurement feature before feeding allows for the processing of varying book thicknesses from one book to the next, enhancing versatility and efficiency. The ESF-1000 offers the flexibility to be manually loaded or connected inline with upstream systems, providing a seamless integration for diverse production environments and requirements.

Production volume

small to medium editions

PRINTING TECHNOLOGY

for offset and digital printing

FORMATS

max. 320 x 630 mm
min. 125 x 128 mm

Speed

max. 390 sheets/min (for A4 format)

GF-500

The space-saving gauze station enables fully automated preparation of the gauze strip, cutting it automatically to the precise length and width based on the book block’s dimensions and thickness. An automatic de-curling feature ensures the gauze is fed accurately and smoothly, enhancing the quality and consistency of the binding process. This unit streamlines the preparation stage, reducing manual intervention and optimizing efficiency, making it a crucial component in modern, automated bookbinding operations.

Production volume

small to medium editions

FORMATS

max. 320 x 630 mm
min. 125 x 128 mm

Speed

max. 390 sheets/min (for A4 format)

PRINTING TECHNOLOGY

for offset and digital printing

LBF-500

The book block feeder LBF-500 is capable of processing various types of book blocks, including loose-sheet collections, folded signatures, glue-assisted, or thread-sewn blocks. It offers versatility in setup, allowing for manual feeding or inline operation when connected to the BQ-500. Additionally, it can be integrated with upstream systems like the end sheet feeder ESF-1000 or the Horizon SmartStacker, providing a seamless and efficient workflow. This adaptability makes the LBF-500 an essential component for diverse bookbinding operations, enhancing productivity and operational flexibility.

Production volume

small to medium editions

PRINTING TECHNOLOGY

for offset and digital printing

Speed

max. 390 sheets/min (for A4 format)

FORMATS

max. 320 x 630 mm
min. 125 x 128 mm
